Centrifugal End Suction ANSI Standart Pump

The Flowsteer Model CN was designed to perform in the toughest industrial applications whether in the chemical, petro-chemical, mining, pulp and paper, consumer products or general industry. If you are considering an ANSI pump for an industrial application, look to Flowsteer Model CN for your pumping solution.

Capacities to 4200 GPM (954 m3/hr)
Heads to 725 Ft. (221 m)
Temperatures to 650?F (343?C)
Pressures to 375 PSIG (2586 kPa)

ANSI Pumps
The Flowsteer Model CN was designed to perform in the toughest industrial
applications whether in the chemical, petro-chemical, mining, pulp and paper,
consumer products or general industry.
If you are considering an ANSI pump for an industrial application, look to Flowsteer
Model CN for your pumping solution.

Model CN S, M / L, XL
The Flowsteer Model CN-S, M/L, and XL were developed with the standard features
required to withstand the most difficult applications and maximize mean-timebetween-failures (MTBF).
• Model CN-S – 5 ASME/ANSI Pumps
• Model CN-M/L – 15 ASME/ANSI Pumps
• Model CN-XL – 5 ASME/ANSI Pumps
